ABB T2L160TMDR63-3P SACE Tmax XT2L 160 Molded Case Circuit Breaker

ABB T2L160TMDR63-3P is a molded case circuit breaker from the ABB SACE Tmax XT series, designed for low-voltage electrical distribution and industrial protection applications. The device combines compact construction, thermomagnetic protection technology and flexible installation characteristics to provide reliable circuit protection in various industrial environments.

The ABB Tmax XT2L 160 platform is designed for applications requiring dependable protection against overload and short-circuit conditions. The T2L160TMDR63-3P configuration includes a three-pole fixed circuit breaker structure with a thermomagnetic TMD release unit rated for 63 A applications. :contentReference[oaicite:1]{index=1}

With its compact frame size and standardized industrial design, ABB T2L160TMDR63-3P is suitable for distribution boards, machinery control systems, industrial electrical panels and automation power supply protection applications.

Product Overview

ABB T2L160TMDR63-3P belongs to the ABB SACE Tmax XT2L 160 family of molded case circuit breakers. The XT2 frame represents a compact MCCB solution within the Tmax XT product range, offering protection functions for electrical systems where space efficiency and reliable interruption performance are required.

The circuit breaker uses a thermomagnetic TMD release system, which combines thermal protection for overload conditions and magnetic protection for short-circuit events. This protection method provides a practical solution for industrial electrical systems without requiring additional electronic control units.

The fixed three-pole configuration allows the breaker to be used in three-phase electrical distribution networks. It is designed for applications requiring stable switching operation and protection coordination within low-voltage installations. :contentReference[oaicite:2]{index=2}

Technical Features

• Product type: Molded case circuit breaker
• Series: ABB SACE Tmax XT
• Frame size: XT2L 160
• Model: T2L160TMDR63-3P
• Number of poles: 3 poles
• Release type: Thermomagnetic TMD
• Rated current: 63 A
• Rated voltage: Up to 690 V AC
• Protection function: Overload and short-circuit protection
• Installation type: Fixed mounting
• Terminal arrangement: Front terminals
• Standard compliance: IEC standards

Thermomagnetic Protection Technology

The ABB T2L160TMDR63-3P uses a thermomagnetic release mechanism to protect electrical circuits from abnormal operating conditions. The thermal protection function responds to prolonged overload currents, while the magnetic protection function provides rapid response during short-circuit events.

Overload conditions may occur when electrical equipment operates beyond its designed capacity for an extended period. Excessive current generates heat inside conductors and connected devices, which can reduce equipment service life and create safety risks.

The thermal release mechanism continuously monitors current levels and activates the protection function when the overload exceeds the defined operating characteristics. The magnetic release provides fast circuit interruption when a short-circuit fault occurs.

Compact XT2L 160 Design

The ABB Tmax XT2L 160 series is designed with a compact structure to optimize space utilization inside electrical cabinets. Compared with larger frame circuit breakers, the XT2 platform provides efficient protection performance while maintaining a reduced installation footprint.

The compact housing design makes ABB T2L160TMDR63-3P suitable for applications where panel space is limited but reliable circuit protection is required. It can be integrated into industrial distribution systems, machine control cabinets and automation electrical assemblies.

The fixed installation configuration simplifies system design and provides a stable mounting solution for low-voltage protection applications.

Electrical Performance

ABB T2L160TMDR63-3P is designed for industrial power distribution systems requiring dependable circuit interruption capability. The XT2L series supports rated operational voltages up to 690 V AC depending on configuration and application conditions. :contentReference[oaicite:3]{index=3}

The three-pole design allows the circuit breaker to protect three-phase loads, including industrial motors, distribution circuits and electrical equipment. The breaker provides coordinated protection against overload and short-circuit faults to improve system reliability.

The thermomagnetic release configuration provides a straightforward protection solution for applications where adjustable electronic protection functions are not required.

Applications

ABB T2L160TMDR63-3P is widely used in industrial electrical systems and automation applications. Typical applications include:

• Industrial power distribution panels
• Motor control centers
• Automation control cabinets
• Machine protection systems
• Building electrical distribution
• Industrial equipment protection
• Three-phase power circuits

The breaker is suitable for environments where electrical loads require dependable protection against overload and short-circuit conditions.

Integration with Industrial Systems

ABB T2L160TMDR63-3P can be integrated with industrial electrical systems together with contactors, motor protection devices, control components and distribution equipment. Its standardized MCCB structure allows engineers to design coordinated protection systems according to different application requirements.

In automation environments, the circuit breaker provides the protection layer between incoming power sources and connected equipment. This helps improve operational stability and reduces the impact of electrical faults on downstream components.

Installation and Maintenance Characteristics

The fixed three-pole design of ABB T2L160TMDR63-3P provides a simple installation method for electrical panels. Front terminal connections support convenient cable arrangement and maintenance access.

The compact design of the Tmax XT series allows efficient cabinet organization, especially in applications where multiple protection devices are installed together.

The mechanical structure is designed for repeated switching operations and industrial operating environments, providing long-term stability for electrical protection systems.

Conclusion

ABB T2L160TMDR63-3P SACE Tmax XT2L 160 Molded Case Circuit Breaker is a compact and reliable protection device designed for industrial low-voltage electrical systems. With a three-pole configuration, thermomagnetic TMD release and 63 A rated current capability, it provides effective overload and short-circuit protection.

The combination of ABB Tmax XT technology, compact construction and flexible industrial application characteristics makes the T2L160TMDR63-3P suitable for power distribution systems, automation equipment and industrial electrical installations requiring dependable circuit protection.
