ABB SH201-15C Miniature Circuit Breaker

Product Overview

ABB SH201-15C is a miniature circuit breaker designed for dependable low voltage electrical protection applications. As a member of the ABB SH200 series, this circuit protection device is developed to provide reliable protection against overload currents and short circuit faults in electrical distribution systems. The product combines ABB’s electrical engineering technology with a compact modular structure, making it suitable for modern residential, commercial, and industrial power distribution environments.

The ABB SH201-15C features a single pole configuration, a 15A rated current, and a C characteristic trip curve. This configuration allows the circuit breaker to provide balanced protection performance for electrical circuits that may experience moderate starting currents during normal operation. It is designed to disconnect abnormal current conditions efficiently while maintaining stable operation under standard electrical loads.

The SH200 series represents ABB’s range of miniature circuit breakers developed for low voltage applications. These devices are designed with practical installation features, reliable mechanical operation, and flexible application possibilities. ABB SH201-15C follows this product philosophy by providing efficient circuit protection within a compact modular housing. :contentReference[oaicite:2]{index=2}

Product Features

ABB SH201-15C incorporates several important features that support safe and reliable electrical system operation. The device combines thermal and electromagnetic protection functions to respond effectively to different types of abnormal current conditions.

• Single pole miniature circuit breaker structure
• 15A rated current for low voltage circuit applications
• C characteristic trip curve for general electrical loads
• Protection against overload and short circuit conditions
• Compact modular design for electrical distribution panels
• DIN rail mounting compatibility
• Clear switching position indication
• Reliable mechanical endurance and electrical performance
• Suitable for residential, commercial, and industrial applications

Technical Specifications

The ABB SH201-15C belongs to the SH200 C characteristic miniature circuit breaker range. ABB provides multiple current ratings and pole configurations within this product family to meet different electrical installation requirements. :contentReference[oaicite:3]{index=3}

Protection Function

The primary purpose of ABB SH201-15C is to protect electrical circuits from damage caused by excessive current. The device uses thermal protection technology to respond to continuous overload situations and electromagnetic protection technology to react quickly during short circuit events.

When an electrical circuit experiences a prolonged overload condition, the internal thermal release mechanism detects the increase in current and disconnects the circuit after reaching the required operating condition. This helps prevent overheating of cables and connected electrical components.

During short circuit conditions, the electromagnetic release mechanism provides rapid circuit interruption. This fast response helps reduce the impact of fault currents and improves the overall safety of electrical installations.

The C characteristic curve of ABB SH201-15C allows the device to handle moderate temporary current peaks generated by certain electrical equipment while maintaining effective protection against dangerous fault conditions. This makes it suitable for circuits containing equipment with higher initial current requirements.

Compact Design and Installation Advantages

ABB SH201-15C features a compact modular structure designed for efficient integration into electrical distribution boards. The standardized housing allows multiple circuit breakers and protection devices to be installed together while optimizing available panel space.

The DIN rail mounting design simplifies installation and replacement processes. Electrical engineers can easily integrate ABB SH201-15C into distribution systems while maintaining a clean and organized panel layout.

The product design also includes clear operating status indication, allowing users and maintenance personnel to quickly identify the switching condition of the circuit breaker. This improves operational convenience and supports efficient electrical system management.

Application Areas

ABB SH201-15C is suitable for a wide range of low voltage electrical protection applications. Its reliable performance and compact structure make it applicable in different environments where individual circuit protection is required.

• Building electrical distribution systems
• Residential power protection applications
• Commercial electrical installations
• Industrial control panels
• Lighting and auxiliary power circuits
• Automation equipment protection systems
• Low voltage control circuits

The combination of 15A rated current and C characteristic operation makes ABB SH201-15C a practical solution for circuits requiring dependable protection and stable electrical performance.

ABB SH200 Series Overview

The ABB SH200 series is a family of miniature circuit breakers developed for reliable low voltage protection. The series includes different current ratings, trip characteristics, and pole configurations, allowing engineers to select suitable protection solutions for various electrical systems.

Within this product family, ABB SH201-15C represents a single pole circuit breaker configuration designed for applications requiring a 15A protection rating. The product maintains ABB’s focus on electrical safety, installation efficiency, and long-term operational reliability.

Operational Reliability

Electrical protection devices play an important role in maintaining system stability. ABB SH201-15C is designed to provide consistent protection performance throughout its operating life. Its mechanical structure and internal protection mechanisms support reliable switching and fault interruption.

The product is suitable for professional electrical installations where dependable circuit protection is required. By combining compact dimensions with effective protection functions, ABB SH201-15C helps improve the safety and efficiency of low voltage electrical systems.

Conclusion

ABB SH201-15C miniature circuit breaker is a reliable low voltage protection component designed for modern electrical distribution applications. With a single pole configuration, 15A rated current, C characteristic trip curve, and compact DIN rail mounting design, it provides effective protection against overload and short circuit conditions.

As part of the ABB SH200 series, ABB SH201-15C delivers practical installation advantages, stable electrical performance, and flexible application capability. Its reliable protection functions make it suitable for residential, commercial, industrial, and automation-related electrical systems requiring efficient circuit protection.
