ABB 3BSE007130R1 PFVI131 Power Supply Unit for PFVA 131 Control Unit and ABB Industrial Automation Systems

The complete ABB identification is 3BSE007130R1, while the corresponding type designation is PFVI131. ABB-related technical references identify PFVI131 as the power supply associated with the PFVA 131 Control Unit.

Product Identification

• Manufacturer: ABB
• Part Number: 3BSE007130R1
• Type Designation: PFVI131
• Product Type: Power Supply Unit
• Associated Control Unit: PFVA 131
• Application: ABB Industrial Automation and Control Systems
• System Family: ABB Advant Control Systems

ABB PFVI131 Overview

The ABB PFVI131 is a dedicated power-supply component used within the PFVA 131 Control Unit configuration. The PFVA 131 assembly consists of several dedicated hardware elements, including a backplane, transformer unit, power supply, processor board, signal processor board, and panel unit. ABB-related product information specifically identifies PFVI131 3BSE007130R1 as the power supply within this architecture.

This modular arrangement separates power conversion and control functions into individual components. As a result, the PFVI131 can be identified independently when maintaining or documenting the corresponding control unit.

The product number 3BSE007130R1 should be retained in full when searching for the component or matching it against system documentation.

Power Supply Function

The primary function of the ABB 3BSE007130R1 is power conversion and regulation for the associated ABB control-system hardware. Available technical information specifies an input voltage range of 85–265 V AC and a regulated output of 24 V DC ±1%.

The power supply therefore provides a stable DC voltage for the compatible control-system circuitry. Its regulated output is an important part of maintaining consistent operation of the electronics connected to the PFVA 131 assembly.

Input Voltage Range

The PFVI131 is specified with a wide AC input range of 85 to 265 V AC. This broad input range allows the power supply to accommodate different industrial AC supply conditions within its specified operating limits.

The incoming supply must always be matched to the applicable electrical requirements before the unit is installed into an operating system.

24 V DC Output

The ABB 3BSE007130R1 provides a regulated output of 24 V DC ±1%. This regulated DC supply is intended for the compatible ABB control-system electronics.

The available technical specification identifies a maximum output current of 25 A and a minimum load of approximately 1.5 A. The corresponding maximum output power is approximately 600 W at 25 A.

Electrical Specifications

Power Conversion Architecture

The PFVI131 converts the incoming AC supply into regulated low-voltage DC power for the associated control hardware. The wide input range and regulated output make the power-supply stage suitable for the industrial control environment for which the PFVA 131 assembly was designed.

The separation of the power supply from the processor and signal-processing boards allows the PFVA 131 architecture to use dedicated hardware for different functional areas.

PFVA 131 Control Unit Relationship

The ABB PFVI131 should be considered in the context of the PFVA 131 Control Unit. Product information for the PFVA 131 identifies PFVI131 3BSE007130R1 as its power supply component, alongside PFVK 138 as the backplane, PFVK 135 as the processor board, PFVK 134 as the signal processor board, and PFVO 131 as the panel unit.

This relationship is important when identifying the correct component for an existing ABB installation. The PFVI131 is not simply a generic 24 V industrial power supply; it is a designated component within the relevant ABB control-unit architecture.

ABB Advant Control System Applications

The PFVI131 is associated with ABB Advant control-system equipment. Product references classify the component within ABB Advant OCS and Advant 800xA-related product categories.

Advant control architectures use dedicated electronic hardware for control processing, signal processing, operator interaction, power distribution, and system interfacing. The PFVI131 provides the power-supply function within its associated hardware assembly.

Power Protection and Regulation

The available PFVI131 technical information identifies an inrush current below 30 A. It also specifies a regulated 24 V DC output and electrical efficiency of at least 89% at 230 V AC and 50% load.

The power factor is specified at approximately 0.98 or higher with active power-factor correction. These characteristics are relevant to the electrical behavior of the power-supply stage under industrial operating conditions.

Hold-Up Performance

The PFVI131 specification identifies a hold-up time of at least 20 ms at 25 A and 230 V AC.

Hold-up performance allows the power supply to maintain its DC output for a specified period during short interruptions or disturbances of the incoming AC supply.

System Integration

The ABB 3BSE007130R1 is intended to function as part of a larger ABB control assembly rather than as an independent control device. Its electrical output must be compatible with the equipment supplied by the PFVI131.

Before installation, the complete part number, associated control-unit model, wiring arrangement, input voltage, output requirements, and system documentation should be checked.

This is particularly important when working with legacy industrial automation equipment where several power-supply assemblies may have similar electrical ratings but different mechanical or system interfaces.

Maintenance and Replacement

For maintenance purposes, the identification ABB PFVI131 3BSE007130R1 provides a precise reference for the power-supply component.

The physical product marking should be compared with the equipment documentation before replacement. Revision information and associated assembly numbers should also be recorded when available.

The PFVI131 should be replaced only with a component that is confirmed to be compatible with the corresponding PFVA 131 control-unit configuration.

Technical Documentation Reference

ABB-related product records identify 3BSE007130R1 as the PFVI131 power supply and associate it with the PFVA 131 Control Unit. Another industrial parts reference also lists 3BSE007130R1 as a power supply within ABB’s Advant OCS and Advant 800xA product category.

For engineering identification, the part number and type designation should be used together:
ABB PFVI131 — 3BSE007130R1.

Industrial Automation Applications

Power-supply components such as the PFVI131 are essential to industrial control architectures because electronic processing and signal-management hardware require stable DC power.

Within its associated ABB control-unit configuration, the PFVI131 supplies the regulated DC power required by the compatible control electronics. Its electrical specifications make it a dedicated industrial power-supply component rather than a general-purpose low-voltage adapter.

Product Identification for Online Catalogues

A suitable technical product name for an industrial automation catalogue is:

ABB 3BSE007130R1 PFVI131 Power Supply Unit for PFVA 131 Control Unit

Useful search variations include ABB 3BSE007130R1, ABB PFVI131, ABB PFVI 131 Power Supply, ABB PFVA 131 Power Supply, ABB 3BSE007130R1 Power Supply Unit, and ABB Advant PFVI131.

Part Number Verification

The complete identification is ABB 3BSE007130R1, with the type designation PFVI131. Product references consistently identify this number as the ABB PFVI131 power supply.

The PFVA 131 component list also identifies PFVI131 3BSE007130R1 as the power supply and places it alongside the other dedicated PFVA 131 control-unit components.

Conclusion

The ABB 3BSE007130R1 is the PFVI131 Power Supply Unit associated with the ABB PFVA 131 Control Unit. It provides a regulated 24 V DC ±1% output and accepts an input range of 85–265 V AC, with a maximum output current of approximately 25 A according to available technical specifications.

The component forms part of an ABB industrial control architecture and should be identified by both its type designation and complete part number. For technical cataloguing and search purposes, the recommended identification is ABB 3BSE007130R1 PFVI131 Power Supply Unit for PFVA 131 Control Unit.
