ABB 2CDS252001R0164 S202-C16 Miniature Circuit Breaker
The ABB 2CDS252001R0164, also known as S202-C16, is a miniature circuit breaker (MCB) from the ABB S200 series designed for reliable electrical protection in industrial and commercial low-voltage systems. It is engineered to protect electrical circuits from overload and short-circuit faults, ensuring safe and stable power distribution operation.
This device is widely used in DIN rail mounted distribution boards and control panels. It provides dependable circuit interruption performance and is compliant with international electrical safety standards such as IEC 60898 and IEC 60947-2, making it suitable for both residential and industrial applications. :contentReference[oaicite:1]{index=1}
Key Features of ABB 2CDS252001R0164
- 2-pole miniature circuit breaker (MCB)
- Rated current: 16A
- C-curve tripping characteristic
- Rated voltage: 230/400V AC
- Short-circuit breaking capacity: up to 6kA
- DIN rail mounting design
- Compact S200 series structure
- Reliable overload and short-circuit protection
Industrial Application Areas
The ABB S202-C16 circuit breaker is widely used in electrical distribution systems where reliable circuit protection is required. It ensures safe operation of electrical installations by automatically disconnecting faulty circuits under abnormal conditions.
- Industrial power distribution panels
- Commercial building electrical systems
- Automation control cabinets
- HVAC electrical systems
- Lighting distribution systems
- Machine and equipment protection circuits
- Residential and commercial switchboards
- General low-voltage electrical systems
Operating Principle
Miniature circuit breakers operate using thermal and magnetic protection mechanisms. The thermal element protects against overload conditions by responding to prolonged excess current, while the magnetic element provides instantaneous protection against short-circuit faults.
When abnormal current conditions occur, the ABB 2CDS252001R0164 automatically interrupts the circuit, preventing damage to electrical equipment and reducing fire risk in the system.
Technical Advantages
| Feature | Benefit |
|---|---|
| 16A Rated Current | Suitable for standard industrial and commercial loads |
| C-Characteristic Curve | Optimized for general-purpose applications |
| 6kA Breaking Capacity | Reliable short-circuit protection performance |
| Compact Design | Easy installation in DIN rail panels |
| Dual Protection System | Thermal and magnetic trip mechanisms |
| ABB Engineering Quality | Ensures long-term reliability and safety |
Designed for Electrical Safety
Electrical safety is essential in modern power distribution systems. The ABB 2CDS252001R0164 provides reliable circuit protection by quickly isolating faulty circuits, reducing the risk of equipment damage and electrical hazards.
Its fast response and stable performance make it suitable for continuous operation in demanding industrial environments where system reliability is critical.
ABB S200 Series Reliability
ABB is a global leader in electrical protection and automation technologies. The S200 series miniature circuit breakers are widely recognized for their durability, precision, and compliance with international standards.
The ABB 2CDS252001R0164 reflects this engineering quality, offering consistent performance and long service life in a wide range of electrical applications.
Conclusion
The ABB 2CDS252001R0164 S202-C16 miniature circuit breaker is a reliable solution for electrical protection in industrial and commercial systems. It provides effective overload and short-circuit protection with stable performance and compact design.
Widely used in distribution boards, control panels, and electrical systems, this ABB MCB ensures safe operation and long-term reliability in modern electrical infrastructure.
