ABB 1SVR040001R0400 CC-U/STD Universal Analog Signal Converter for Industrial Control Systems

The complete ABB product identification is 1SVR040001R0400, while the extended product type is CC-U/STD. The product is designed for DIN rail mounting and supports a wide range of analog signal configurations through accessible DIP switches. :contentReference[oaicite:2]{index=2}

Product Identification

• Manufacturer: ABB
• Product ID: 1SVR040001R0400
• Extended Product Type: CC-U/STD
• Product Family: CC-U
• Product Type: Universal Analog Signal Converter
• Mounting: DIN Rail
• Supply Voltage: 110–240 V AC / 100–300 V DC
• Electrical Isolation: Three-Way Isolation
• Programming: DIP Switch Configuration
• EAN: 4013614362897

ABB CC-U/STD Overview

The ABB CC-U/STD is a configurable analog signal converter intended to process and convert industrial standard signals. Its universal configuration allows the same device to accommodate numerous input and output signal combinations.

ABB technical information specifies 28 configurable input signal ranges, including 16 standard and 12 non-standard ranges, together with 41 configurable output signal ranges, including 8 standard and 33 non-standard ranges. These configurations can be selected through lateral DIP switches. :contentReference[oaicite:3]{index=3}

Universal Signal Conversion

Signal conversion is an important function in industrial automation systems because different sensors, transmitters, controllers and monitoring devices may use different electrical signal formats.

A universal signal converter can adapt an incoming analog signal to the format required by another part of the control system. This allows different signal standards to be integrated into a common automation architecture.

The ABB 1SVR040001R0400 provides configurable input and output ranges, making it suitable for a variety of analog signal-processing requirements.

Three-Way Electrical Isolation

One of the key features of the CC-U/STD is its three-way electrical isolation.

Electrical isolation separates the signal circuits from one another and from the power supply. This can help reduce the influence of electrical potential differences and unwanted signal interactions within an industrial control installation.

The isolated design is particularly useful in industrial environments where multiple instruments and control devices operate at different electrical potentials.

Input Signal Configuration

The ABB 1SVR040001R0400 supports a broad range of analog input signals.

ABB documentation lists the configurable input range as approximately ±0.9 mA to ±55 mA, ±45 mV to ±11 V, and resistance-related ranges from approximately 470 ohms to 1 megohm. :contentReference[oaicite:4]{index=4}

This broad input capability allows the converter to interface with different types of analog instrumentation and control signals.

Output Signal Configuration

The CC-U/STD also provides configurable analog outputs.

The published product information identifies output ranges up to approximately ±55 mA and ±11 V, depending on the selected configuration. :contentReference[oaicite:5]{index=5}

Output configuration can therefore be selected according to the requirements of the receiving controller, indicator, recorder or other industrial device.

DIP Switch Configuration

The ABB 1SVR040001R0400 uses directly accessible lateral DIP switches for configuration.

The DIP switches allow the required input and output signal ranges to be selected without requiring an external programming interface. This provides a practical method of configuring the signal converter for different automation applications.

The selected switch positions should correspond to the required signal range and the instructions provided for the specific CC-U/STD configuration.

Gain and Offset Adjustment

The CC-U/STD provides front-side operating elements for gain and offset adjustment.

Gain adjustment can be used to establish the required relationship between the input and output signals, while offset adjustment allows the signal baseline to be aligned with the intended application.

These adjustment functions provide additional flexibility when integrating the converter into analog measurement and control circuits.

Control Supply

The ABB 1SVR040001R0400 is designed for a broad control-supply range.

Published technical data specifies a rated control supply of 110–240 V AC and also identifies a DC supply range of 100–300 V DC. :contentReference[oaicite:6]{index=6}

The appropriate supply must be selected according to the installation requirements and the product’s technical documentation.

DIN Rail Mounting

The ABB 1SVR040001R0400 is designed for DIN rail mounting. This allows the compact signal converter to be installed alongside other control components inside industrial electrical cabinets.

DIN rail installation is widely used for interface modules, signal conditioners, relays, circuit protection devices and other automation components.

Short-Circuit-Proof Signal Outputs

The CC-U/STD provides short-circuit-proof signal outputs.

This feature is useful in industrial control installations where wiring faults or temporary output-side problems may occur. The output design contributes to the robustness of the signal interface within the control system.

Plug-In Connecting Terminals

The ABB CC-U/STD uses plug-in connecting terminals for the input, output and supply connections. :contentReference[oaicite:7]{index=7}

Plug-in terminals can simplify wiring and maintenance because the connection arrangement is designed around removable terminal blocks.

LED Power Indication

The applied supply voltage is indicated by a green LED on the unit. :contentReference[oaicite:8]{index=8}

This visual indication provides a convenient way to identify the presence of the control supply during system inspection.

Signal Interruption Detection

The CC-U/STD provides configurable detection of input signal interruption.

The response can be configured for low fail-safe or high fail-safe behavior depending on the requirements of the application. :contentReference[oaicite:9]{index=9}

This function can be important in control systems where an interrupted signal needs to be interpreted in a defined manner.

Signal Processing Applications

The ABB 1SVR040001R0400 is suitable for applications involving analog signal processing and conversion.

Potential applications include signal interfacing between field instruments and controllers, analog signal adaptation, measurement systems, monitoring equipment and industrial process-control installations.

The actual application depends on the selected input and output ranges and the requirements of the connected equipment.

Industrial Automation Integration

Industrial automation systems commonly contain devices operating with different signal standards. A signal converter provides an interface between these devices.

For example, a field instrument may generate one analog signal while a controller or monitoring system expects another. A configurable converter can adapt the signal to the required format.

The ABB CC-U/STD is designed specifically for this type of interface function.

Analog Signal Conditioning

Signal conditioning can involve conversion, isolation, scaling and adjustment of analog signals.

The ABB 1SVR040001R0400 combines these functions in a compact DIN rail device. Its configurable ranges allow it to accommodate different signal requirements within the same product platform.

Technical Specifications

Compact DIN Rail Design

The unit has a product width of approximately 22.5 mm, with a height of approximately 105 mm and depth of approximately 120 mm. The published net weight is approximately 0.126 kg. :contentReference[oaicite:10]{index=10}

The compact housing makes the CC-U/STD suitable for installation in control cabinets where DIN rail space is an important consideration.

Accuracy and Response

Published technical information specifies an accuracy of approximately ±0.1% of full scale and a response time of approximately 200 microseconds. :contentReference[oaicite:11]{index=11}

These characteristics make the converter suitable for applications where accurate analog signal transmission and relatively fast signal response are required.

Operating Temperature

Published product information provides operating-temperature information for the CC-U/STD, with values depending on the referenced specification. One product listing identifies a range of approximately -20 °C to +60 °C, while another catalog listing gives a broader temperature specification for certain conditions. :contentReference[oaicite:12]{index=12}

The installation temperature should therefore be checked against the applicable ABB technical documentation for the specific operating conditions.

Industrial Control Cabinet Applications

The ABB 1SVR040001R0400 can be installed within industrial control cabinets together with controllers, interface modules, relays, circuit protection equipment and other signal-processing components.

Its DIN rail mounting and compact housing allow it to occupy a small amount of cabinet space while providing configurable analog signal conversion.

Measurement and Monitoring Systems

Analog signal converters are commonly used in measurement and monitoring systems to adapt signals from field devices to the input requirements of monitoring or control equipment.

The universal input and output configuration of the CC-U/STD allows it to support different signal types without requiring a separate converter for every individual signal format.

Process Control Applications

In process-control systems, analog signals can represent process variables such as pressure, temperature, flow, level or other measured conditions.

A signal converter can provide electrical isolation and signal adaptation between field instrumentation and the control system.

The ABB CC-U/STD is therefore applicable to a wide range of industrial signal-interface requirements.

Configuration Verification

Before commissioning the ABB 1SVR040001R0400, the input and output configuration should be checked against the intended signal levels.

The DIP-switch settings, gain adjustment and offset adjustment should correspond to the connected equipment and required signal relationship.

Incorrect signal configuration can result in inaccurate signal scaling or inappropriate system response.

Electrical Connection

The CC-U/STD provides plug-in connection terminals for the relevant input, output and supply circuits.

The wiring arrangement should be established from the applicable connection diagram and installation documentation. Particular attention should be given to the supply voltage and selected input/output ranges.

Maintenance Considerations

Maintenance of an ABB 1SVR040001R0400 installation can include checking the control supply, terminal connections, DIP-switch configuration, LED indication and analog signal values.

Because the device is part of a signal chain, troubleshooting should consider both the input source and the receiving equipment.

The selected signal configuration should also be compared with the system design documentation whenever a signal problem is investigated.

Product Identification for Inventory

For technical inventory systems, the recommended primary identification is:

ABB 1SVR040001R0400 CC-U/STD Universal Signal Converter

Useful search variations include ABB 1SVR040001R0400, ABB CC-U/STD, ABB CC-U STD Signal Converter, ABB Universal Analog Signal Converter and ABB 1SVR040001R0400 Signal Conditioner.

Product Number Verification

The complete product number 1SVR040001R0400 should be retained when identifying this ABB component.

The product ID and extended product type are separately documented as 1SVR040001R0400 and CC-U/STD. The EAN associated with the product is 4013614362897. :contentReference[oaicite:13]{index=13}

This information helps distinguish the product from other ABB CC-U series signal converters with different ordering numbers and configurations.

Product Lifecycle Information

ABB’s published low-voltage product lifecycle documentation lists the 1SVR040001R0400 within the CC-U product line and indicates that the CC-U line reached a discontinued or obsolete lifecycle status. :contentReference[oaicite:14]{index=14}

Some distributor databases may still show differing commercial status information, so lifecycle status should be distinguished from the technical identification of the product. :contentReference[oaicite:15]{index=15}

Conclusion

The ABB 1SVR040001R0400 is a CC-U/STD universal analog signal converter designed for industrial signal processing and control applications. It provides three-way electrical isolation, configurable input and output ranges, DIP-switch configuration, front-side gain and offset adjustment, short-circuit-proof outputs and plug-in terminals. :contentReference[oaicite:16]{index=16}

With DIN rail mounting, a compact 22.5 mm width and a broad control-supply range of 110–240 V AC or 100–300 V DC, the device is designed for integration into industrial control cabinets and analog signal-interface systems. :contentReference[oaicite:17]{index=17}

For product identification, technical cataloguing and search purposes, the complete designation ABB 1SVR040001R0400 together with the product type CC-U/STD Universal Signal Converter should be used.
